Thermocouple Sensor Probes and Assemblies

The thermocouple is a temperature sensor created by joining two dissimilar metals together to form a sensing junction. The output is a very small EMF, which has a predictable value to the temperature of the sensing junction in reference to a reference junction.


Thermocouple Technical Information

The following material is general thermocouple information to assist and reference in the application of thermocouples to your process requirements.

Thermocouple Overview and Temperature Reference Chart

Thermocouple Tolerance

Thermocouple Junctions and Response Time


Thermocouple Sensor Probes

The TC series Thermocouple sensor probes come in various styles unique to different applications. Each style consists of a thermocouple sensing junction protected by a sheath with a termination option.

Thermocouple Sensor Probes

Features:

  • Styles are customizable to almost any application.

  • Manufactured from high quality raw materials that meet industry recognized standards.

  • Fast lead time on styles that utilize standard Aircom materials.

Application: Thermocouple sensor probes are used widely across almost any and every commercial and industrial temperature process control application.

Thermocouple Sensor Probe Model TC4

Bayonet Thermocouple Sensor Probes

Handheld Thermocouple Sensor Probe

Handheld-Thermocouple-Sensor-Probes

Handheld thermocouple sensor probes are commonly used in conjunction with a handheld thermocouple reader. Aircom is capable of manufacturing custom hand held probes to suit your specific requirements.


Thermocouple Assembly Model TC8

The TC8 Thermocouple assembly is a temperature sensor assembly consisting of a thermocouple sensor probe, tapered thermowell, conduit nipples, union, spring loading terminal block, and connection head.

Features:

  • Thermocouple sensor probe is removable for verification, maintenance and replacement.

  • Simple design that is used and accepted across multiple process industries.

  • Tapered thermowell profile provides a good strength to response time balance.

Application: Thermocouple assemblies are used widely across almost any and every industrial process control environment.


Thermocouple Assembly Model TC10

The TC10 Thermocouple assembly is a temperature sensor assembly consisting of a thermocouple sensor probe, various fitting options, and optional connection head and terminal block.

Features:

  • Simple design that is used and accepted across multiple process industries.

  • Direct mount process temperature transmitter using the TXUN fitting option.

  • TC10 configuration options allow for many different patterns to be configured for almost any temperature measurement application.

Application: Thermocouple assemblies are used widely across almost any and every industrial process control environment.

Commonly TC10s are accompanied by a thermowell. Click on the images or titles below to download/view PDFs with information about thermowells. Or click here to go to our Thermowells and Protection Tubes product page.


Ceramic Thermocouple Sensor Probes

Ceramic thermocouple sensor probes are used in elevated temperature applications as the ceramic materials can be exposed to temperatures well above 1000° celcius. Fragile by nature, these styles are typically used inside a protection tube made from a ceramic or silica carbide material.


Break To Length Thermocouple and RTD Sensor


Break To Length Sensor Probe

The Break To Length thermocouple and RTD sensor is designed to be used inside thermowells. The temperature sensor is manufactured in such a way that the end user can “break” the sensor to the desired length needed to suit the application.
